Mesh add tabs

GPT-6 Astra, effort high$0.881m 19s1m 18s waiting on the model2 builds

Reference
iso
front
back
top
bottom
left
right

100of 100

built: 100
geometry: 100
AI judge: 8 of 8

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The lid retains its original recessed-plate silhouette and two flat tabs with holes extend past the short ends.
- GPT-5.6 Sol: pass: The result retains the same rounded rectangular enclosure-lid form and raised perimeter lip, with two holed tabs added at opposite short ends.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The lid proportions match the reference and the tabs are small relative to the lid as expected.
- GPT-5.6 Sol: pass: The lid body, rim, plate thickness, and corner proportions visually agree with the reference while the added tabs remain appropriately small relative to the lid.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The lid's rim/lip is preserved and both mounting tabs with through-holes are present.
- GPT-5.6 Sol: pass: The flat lid panel, rounded outer plate, and continuous raised perimeter lip visible in the reference are all present, along with the requested tabs and holes.
Pass:Those features sit where the reference has them, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: Tabs sit centered on each short end and holes are centered in the tabs, matching the request.
- GPT-5.6 Sol: pass: The lid panel and perimeter lip remain in their reference locations, and the new tabs are centered on the two opposing short ends.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: No extra decorative geometry beyond the requested tabs and holes appears in the renders.
- GPT-5.6 Sol: pass: No unexplained decorative geometry or extra openings are visible beyond the requested pair of mounting tabs and holes.
Pass:The tabs read as flat flanges continuing the lid's outer face, not posts, brackets or blocks bolted onto it
- Opus 4.8: pass: The side views show the tabs continue as thin flat plates flush with the lid's outer face rather than posts or blocks.
- GPT-5.6 Sol: pass: Both tabs are thin flat extensions aligned with the lid's lower outer plate face rather than raised posts, brackets, or blocks.
Pass:Each tab carries exactly one round hole and no other openings
- Opus 4.8: pass: Each tab shows exactly one round hole in the top and bottom views.
- GPT-5.6 Sol: pass: The top and isometric views clearly show exactly one round opening in each tab and no additional tab openings.
Pass:Each tab is joined to the lid along its end rather than floating beside it or touching at a corner
- Opus 4.8: pass: The tabs join the lid across its full short-end edge rather than floating or touching at a corner.
- GPT-5.6 Sol: pass: Each tab shares a substantial edge connection with the corresponding short end of the lid rather than floating or touching only at a corner.

Measured

✓ watertight: true == true
✓ one sub-part named lid: ok
✓ the imported lid is still declared as an import: ok
✓ the lid's own volume survives: ok
✓ nothing solid was added inside the lid's own footprint: ok
✓ the part spans 12 mm past the lid at both ends together: ok
✓ the tabs are on the short ends, not the long ones: ok
✓ the -X tab hole clears 3.4 mm at the 102 mm pitch: ok
✓ the +X tab hole clears 3.4 mm at the 102 mm pitch: ok
✓ the -X tab fills the lid's own thickness beyond its hole: ok
✓ the +X tab fills the lid's own thickness beyond its hole: ok
✓ asked the oracle at most once: ok
