Photo resistor

GPT-6 Sol, effort high$0.141m 18s1m 16s waiting on the model2 builds

Reference
iso
front
back
top
bottom
left
right

97of 100

built: 100
geometry: 93
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 5.5: pass: The top render shows a rectangular finned body with two diagonally opposed holed tabs, matching the photo's silhouette from above.
- GPT-6 Sol: pass: The renders show the same elongated finned housing with mounting flanges on opposite sides.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 5.5: pass: In the top view, the body length-to-width ratio and the tab size relative to the body closely match the reference photo.
- GPT-6 Sol: pass: The body’s length-to-width ratio and the flange sizes appear close to those in the reference.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 5.5: pass: Both mounting flanges with holes and the longitudinal grooves along both long sides are present.
- GPT-6 Sol: pass: Both mounting flanges, their holes, and the lengthwise fins and grooves are visible.
Pass:Those features sit where the reference has them
- Opus 5.5: pass: The upper flange sits at the right end and the lower flange at the left end, as in the photo, with the grooves running along the top and bottom edges.
- GPT-6 Sol: pass: The flanges sit near opposite ends on opposite sides, matching the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 5.5: pass: Only the body, its fins and the two flanges are modelled, with no extra decorative geometry.
- GPT-6 Sol: pass: The renders show no apparent decorative or unexplained features.
Pass:A rectangular finned extrusion with a flat base, grooved along both long sides — not a cylinder or a plain block
- Opus 5.5: pass: The body is a flat-based rectangular extrusion with ridges and grooves running along both long sides, visible in the iso and end views.
- GPT-6 Sol: pass: The housing is a rectangular extrusion with a flat base and lengthwise grooves along both long sides.
Pass:No wires, lugs or terminals modelled at either end
- Opus 5.5: pass: No wires, lugs or terminals appear at either end in any render.
- GPT-6 Sol: pass: No wires, solder lugs, or terminals appear at either end.

One reviewer

Verdict: acceptable (from the ranking's acceptable line, not typed on this attempt)

Measured

✓ watertight: ok
✓ one sub-part named housing: ok
✓ length is 50 mm: ok
✓ width over the flanges: ok
✗ height is 15.39 mm: predicate returned false
✓ two through-holes: ok
✓ the -X flange hole clears 3.7 mm: ok
✓ the -X flange is there around its hole: ok
✓ the -X flange is on one side only: ok
✓ the -X hole is 3.7 mm, not a slot: ok
✓ the +X flange hole clears 3.7 mm: ok
✓ the +X flange is there around its hole: ok
✓ the +X flange is on one side only: ok
✓ the +X hole is 3.7 mm, not a slot: ok
✓ the leads were not modelled: ok
