608 bearing seat

Opus 5.5, effort high$0.241m 1s59s waiting on the model4 builds, 2 failed

91of 100

What the AI judge checked

Pass:A square plate of uniform outer thickness
- Opus 5.5: pass: Top/bottom views show a square outline and side views show a uniform rectangular profile of constant thickness.
- GPT-6 Sol: pass: The renders show a square plate with straight sides and uniform outer thickness.
Pass:A central bore with a visible wider step at the top, not a plain straight hole
- Opus 5.5: pass: The isometric and top views show a wider counterbore ring with a visible step ledge above the narrower through-bore.
- GPT-6 Sol: pass: A circular ledge is visible inside the central bore below its wider top opening.
Pass:Four small holes near the corners on a square pattern
- Opus 5.5: pass: Four small through-holes appear near the corners in a symmetric square pattern in the top and bottom views.
- GPT-6 Sol: pass: Four small holes appear near the corners in a square pattern.
Pass:The central bore is open at the bottom face as well as the top
- Opus 5.5: pass: Background is visible through the central bore in both top and bottom views, showing it passes fully through.
- GPT-6 Sol: pass: The bottom view shows the central bore opening through the bottom face.
Pass:Nothing added beyond the stepped bore and the four holes
- Opus 5.5: pass: No extra features beyond the stepped central bore and four corner holes are visible in any render.
- GPT-6 Sol: pass: No features beyond the stepped central bore and four corner holes are visible.
