Bracket second mount

Opus 5.5, effort high$0.471m 31s1m 27s waiting on the model3 builds

100of 100

What the AI judge checked

Pass:An L-shaped bracket: a flat base plate with a wall standing up along one edge
- Opus 5.5: pass: The isometric and side views show a flat base plate with a perpendicular wall rising along one edge.
- GPT-6 Sol: pass: The renders show a flat base plate with an upright wall along one edge.
Pass:Two small round holes through the flat base plate
- Opus 5.5: pass: Two small round holes are visible through the base plate in the isometric and bottom views.
- GPT-6 Sol: pass: Two small round through-holes are visible in the base plate.
Pass:Two small round holes through the upright wall, near its top
- Opus 5.5: pass: Two small round holes appear near the top of the upright wall in the front and back views.
- GPT-6 Sol: pass: Two small round through-holes are visible near the top of the upright wall.
Pass:One much larger round hole through the middle of the upright wall
- Opus 5.5: pass: A large round hole, much bigger than the others, is centred horizontally on the upright wall in the front view.
- GPT-6 Sol: pass: One much larger round through-hole is visible in the middle of the upright wall.
Pass:The large hole does not run into or overlap any of the small holes
- Opus 5.5: pass: In the front view the large hole is separated by solid material from both upper small holes and stays well above the base.
- GPT-6 Sol: pass: The large hole is visibly separated from both upright holes and does not intersect the base holes.

Verdict: acceptable (from the ranking's acceptable line, not typed on this attempt)
