Nema17 face mount

GPT-6 Sol, effort high$0.0420s19s waiting on the model1 build

100of 100

What the AI judge checked

Pass:A flat square plate of uniform thickness
- Opus 5.5: pass: Top view shows a square outline and side views show a uniform-thickness rectangular profile.
- GPT-6 Sol: pass: The renders show a flat square plate with straight sides and uniform thickness.
Pass:One large round hole at the centre of the plate
- Opus 5.5: pass: A single large circular through-hole is visible at the centre in the top and isometric views.
- GPT-6 Sol: pass: One large round through-hole is visible at the plate’s centre.
Pass:Four small round holes arranged on a square around the centre hole
- Opus 5.5: pass: Four small round through-holes sit at the corners of a square around the centre bore in the top view.
- GPT-6 Sol: pass: Four small round holes surround the centre bore in a square pattern.
Pass:The four holes are symmetric about both centre lines of the plate
- Opus 5.5: pass: The small holes are at roughly (273,273), (750,273), (273,750) and (750,750), mirrored about the plate centre at about 512.
- GPT-6 Sol: pass: The four small holes appear evenly spaced on either side of both plate centre lines.
Pass:Nothing on the plate beyond the five holes
- Opus 5.5: pass: No features other than the five holes are visible on the plate in any view.
- GPT-6 Sol: pass: No features beyond the five holes are visible on the plate.
