Nema17 face mount

Opus 5.5, effort high$0.1640s38s waiting on the model3 builds, 1 failed

96of 100

What the AI judge checked

Pass:A flat square plate of uniform thickness
- Opus 5.5: pass: Top view shows a square outline and side views show a constant-thickness rectangular profile.
- GPT-6 Sol: pass: The renders show a flat square plate with straight sides and uniform thickness.
Pass:One large round hole at the centre of the plate
- Opus 5.5: pass: A single large circular through-hole sits at the centre of the plate in the top and bottom views.
- GPT-6 Sol: pass: One large round through-hole is visible at the centre of the plate.
Pass:Four small round holes arranged on a square around the centre hole
- Opus 5.5: pass: Four small round through-holes are arranged at the corners of a square around the central bore.
- GPT-6 Sol: pass: Four small round holes form a square around the central bore.
Pass:The four holes are symmetric about both centre lines of the plate
- Opus 5.5: pass: In the top view, the four small holes sit at equal offsets left/right and up/down from the centre lines.
- GPT-6 Sol: pass: The four small holes appear equally spaced on either side of both plate centre lines.
Pass:Nothing on the plate beyond the five holes
- Opus 5.5: pass: Apart from the five holes, the plate is plain, with no extra features visible in any view.
- GPT-6 Sol: pass: The plate shows only the central bore and four small holes, with no other visible features.

Verdict: acceptable (from the ranking's acceptable line, not typed on this attempt)
