Mesh socket mount

Opus 5.5, effort high$0.261m 16s1m 15s waiting on the model4 builds, 1 failed

Reference
iso
front
back
top
bottom
left
right

96of 100

built: 85
geometry: 100
AI judge: 8 of 8

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle, allowing for the requested change: the result is not the bracket but a flat rectangular panel with a socket cut through it in the bracket's own L-shaped outline, slightly enlarged; the bracket's holes, slots and thickness are not expected to appear in the panel
- Opus 5.5: pass: The result is a flat rectangular panel with an L-shaped through-opening matching the bracket's side profile.
- GPT-6 Sol: pass: The result is a flat rectangular panel with an L-shaped opening corresponding to the bracket’s side profile.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge, allowing for the requested change: the result is not the bracket but a flat rectangular panel with a socket cut through it in the bracket's own L-shaped outline, slightly enlarged; the bracket's holes, slots and thickness are not expected to appear in the panel
- Opus 5.5: pass: The L-opening's leg lengths and thin arms match the bracket's side silhouette (long base, shorter upright, similar thickness ratio).
- GPT-6 Sol: pass: The opening preserves the bracket’s long horizontal leg and shorter upright leg, with a visible border around both.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result, allowing for the requested change: the result is not the bracket but a flat rectangular panel with a socket cut through it in the bracket's own L-shaped outline, slightly enlarged; the bracket's holes, slots and thickness are not expected to appear in the panel
- Opus 5.5: pass: The only expected feature, the L-shaped socket, is present, and holes and slots are not expected.
- GPT-6 Sol: pass: The requested L-shaped socket is visible; the bracket’s mounting holes and slots are appropriately absent from the panel.
Pass:Those features sit where the reference has them, allowing for the requested change: the result is not the bracket but a flat rectangular panel with a socket cut through it in the bracket's own L-shaped outline, slightly enlarged; the bracket's holes, slots and thickness are not expected to appear in the panel
- Opus 5.5: pass: The L socket sits roughly centred in the panel with even margins, consistent with a 10 mm border around the silhouette.
- GPT-6 Sol: pass: The socket’s upright leg is at one end of its horizontal leg, matching the bracket’s arrangement.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry, allowing for the requested change: the result is not the bracket but a flat rectangular panel with a socket cut through it in the bracket's own L-shaped outline, slightly enlarged; the bracket's holes, slots and thickness are not expected to appear in the panel
- Opus 5.5: pass: No extra geometry beyond the panel and the L socket appears in the renders.
- GPT-6 Sol: pass: The renders show only the rectangular panel and its socket, with no decorative or unexplained features.
Pass:The opening is L-shaped, following the bracket's own profile, rather than round, rectangular or a rough approximation of it
- Opus 5.5: pass: The front and back views show a clean L-shaped opening that follows the bracket profile.
- GPT-6 Sol: pass: The opening is distinctly L-shaped rather than a rectangular or round cutout.
Pass:There is exactly one opening through the panel — no extra holes, slots or pockets
- Opus 5.5: pass: Only the single L-shaped opening is visible through the panel.
- GPT-6 Sol: pass: The face-on renders show one connected L-shaped opening and no additional holes or slots.
Pass:The material around the opening is unbroken — no part of the opening runs out to an outer edge of the panel
- Opus 5.5: pass: Solid material surrounds the L opening on all sides, and the opening does not reach any outer edge.
- GPT-6 Sol: pass: Panel material visibly surrounds the opening on every side, with no cut reaching an outer edge.

Measured

✓ watertight: true == true
✓ one sub-part named mount: ok
✓ the imported bracket is still declared as an import: ok
✓ the panel is 95 by 65 mm, 6 mm thick, and stands where the prompt puts it: ok
✓ the socket clears the bracket grown 3 %: ok
✓ the panel is still solid in the L's open corner: ok
✓ the socket is open through the panel where the upright passes: ok
✓ asked the oracle at most once: ok
