Bottle neck adapter

GPT-6 Sol, effort high$0.0743s41s waiting on the model2 builds, 1 failed

GPT-6 Sol's Bottle neck adapter, iso view

iso
front
back
top
bottom
left
right

96of 100

built: 85
geometry: 100
AI judge: 4 of 4

What the AI judge checked

Pass:A straight round tube, open at both ends
- Opus 5.5: pass: The side views show a straight cylinder with parallel sides, and the top and bottom views show an open bore with background visible through it.
- GPT-6 Sol: pass: The renders show a straight cylindrical tube with a visible opening at the top and a through-opening visible from above.
Pass:The wall looks the same thickness all the way round
- Opus 5.5: pass: The end views show a concentric light annulus of even width all the way around the bore.
- GPT-6 Sol: pass: The top rim appears evenly thick around the full circumference.
Pass:No flanges, threads or other features were added
- Opus 5.5: pass: The side views show a plain smooth cylinder, with no flanges, threads or other added features.
- GPT-6 Sol: pass: The exterior is smooth, with no visible flanges, threads, or other added features.
Pass:You can see straight through the tube
- Opus 5.5: pass: The top and bottom views show the background colour through the centre of the bore.
- GPT-6 Sol: pass: The top-down render shows the background through the center of the tube.

Measured

✓ watertight: true == true
✓ holes: 1 == 1
✓ one sub-part named tube: ok
✓ outer is exposed as 20 to 40: ok
✓ inner is exposed as 12 to 36: ok
✓ default tube is 28 across and 30 long: ok
✓ bore tracks inner, capped so the wall stays 1.2 mm: ok
✓ sweep outer=20: watertight: true == true
✓ sweep outer=20: holes: 1 == 1
✓ sweep outer=20: swept build is not empty: ok
✓ sweep outer=20: the bore moves with the controls: ok
✓ sweep outer=20: bore tracks inner, capped so the wall stays 1.2 mm: ok
✓ sweep outer=20: outer tracks the control: ok
✓ sweep outer=40: watertight: true == true
✓ sweep outer=40: holes: 1 == 1
✓ sweep outer=40: swept build is not empty: ok
✓ sweep outer=40: the bore moves with the controls: ok
✓ sweep outer=40: bore tracks inner, capped so the wall stays 1.2 mm: ok
✓ sweep outer=40: outer tracks the control: ok
✓ sweep inner=12: watertight: true == true
✓ sweep inner=12: holes: 1 == 1
✓ sweep inner=12: swept build is not empty: ok
✓ sweep inner=12: the bore moves with the controls: ok
✓ sweep inner=12: bore tracks inner, capped so the wall stays 1.2 mm: ok
✓ sweep inner=36: watertight: true == true
✓ sweep inner=36: holes: 1 == 1
✓ sweep inner=36: swept build is not empty: ok
✓ sweep inner=36: the bore moves with the controls: ok
✓ sweep inner=36: bore tracks inner, capped so the wall stays 1.2 mm: ok
