Nema17 face mount

The request

Make a face-mount plate for a NEMA 17 stepper motor. A 60 mm square plate, 5 mm thick, lying flat in the XY plane and centred on the origin with Z up. Cut a 22.4 mm through-hole at the centre for the motor's pilot boss, and four 3.4 mm through-holes on the motor's 31 mm square bolt pattern, at X = ±15.5 and Y = ±15.5. Name the sub-part exactly `plate`.

What the AI judge checks

• A flat square plate of uniform thickness
• One large round hole at the centre of the plate
• Four small round holes arranged on a square around the centre hole
• The four holes are symmetric about both centre lines of the plate
• Nothing on the plate beyond the five holes

Measured checks

• one sub-part named plate (gate)
• plate is 60 × 60 × 5
• pilot bore is 22.4 mm
• bolt hole at (15.5, 15.5) is 3.4 mm (gate)
• bolt hole at (15.5, -15.5) is 3.4 mm (gate)
• bolt hole at (-15.5, 15.5) is 3.4 mm (gate)
• bolt hole at (-15.5, -15.5) is 3.4 mm (gate)
