Bayonet twist-lock jar

A jar whose lid drops on and locks with a short twist, like a camera lens cap: lugs on the jar ride into L-shaped slots in the cap. Set the size of the jar, how many lugs you want and how far the cap turns, and tune the clearance so it turns freely on your printer. Both parts print with no supports, the jar upright and the cap on its top.

Customize in 3D

Adjust its settings live, then export STL, 3MF or STEP. No account needed.

Likes0Comments0Downloads1

Designed by eugene in PartForge, parametric CAD with an AI collaborator.

License

Public domain dedication

You can build on this forge: its code may be copied into forges the assistant makes for you, always naming this license. No credit required.
