Photo lid

Haiku 5.5, effort high$0.031m 52s1m 50s waiting on the model2 builds

Reference
iso
front
back
top
bottom
left
right

92of 100

built: 100
geometry: 85
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 5.5: pass: The render is a shallow rounded-rectangle open tray with a rib grid and chamfered inner corners, matching the photographed lid seen from above.
- GPT-6 Sol: pass: The render shows the same open, elongated rectangular case lid with rounded outer corners and a ribbed interior.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 5.5: pass: The top view's length-to-width ratio (about 1.63) closely matches the reference (about 1.66), and the walls and rim look comparably thin.
- GPT-6 Sol: pass: The length-to-width ratio and relative size of the rim and grid appear close to the reference.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 5.5: pass: The rib grid, the chamfered inner corners, the four corner magnet pockets and the rounded outer corners are all present.
- GPT-6 Sol: pass: The raised rim, interior rib grid, diagonal inner corner cutoffs, and four round corner pockets are visible.
Pass:Those features sit where the reference has them
- Opus 5.5: pass: The top view shows the same 8x5 cell grid (7 longitudinal-spaced ribs and 4 crosswise ribs), with the pockets at all four corners as in the photo.
- GPT-6 Sol: pass: The grid spans the floor and the four pockets sit at the corresponding corners, as in the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 5.5: pass: No extra geometry beyond the tray, ribs, chamfers and pockets is visible.
- GPT-6 Sol: pass: The renders show no conspicuous geometry absent from the reference.
Pass:Each inner corner is cut off diagonally and carries one small round pocket
- Opus 5.5: pass: Each of the four inner corners has a diagonal chamfer, and a single small round hole sits in the corner rim region.
- GPT-6 Sol: pass: All four inner corners are cut off diagonally, with a small round pocket at each corner.
Pass:An open tray whose walls stand well above the rib grid, with no lid, cover or ribs reaching the rim
- Opus 5.5: pass: The isometric view shows tall walls rising well above the low ribs, with the top open and no ribs reaching the rim.
- GPT-6 Sol: pass: The tray is uncovered, and its perimeter walls stand visibly higher than the floor ribs.

Measured

✓ watertight: ok
✓ one sub-part named lid: ok
✓ the apply was scored against the photo: ok
✓ silhouette matches the photo: ok
✓ length is 174.34 mm: ok
✓ width is 107 mm ± 10 %: ok
✓ height is 17.98 mm: ok
✓ the tray is hollow: ok
✓ the floor is solid: ok
✗ 7 ribs across the length on the 8-pocket pitch: predicate returned false
✗ 4 ribs across the width on the 5-pocket pitch: predicate returned false
✓ every pocket is open above its floor: ok
✓ the ribs stop below the rim: ok
