Mesh rebuild scan

Gemini 3.8 Flash$0.191m 16s1m 12s waiting on the model7 builds, 1 failed

Reference
iso
front
back
top
bottom
left
right

96of 100

built: 85
geometry: 100
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 4.8: pass: The clean render shows a rectangular block with a single round hole, matching the scan's form and silhouette.
- GPT-5.6 Sol: pass: The result has the same rectangular block silhouette with a single circular opening as the reference.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 4.8: pass: The block's length, width and height ratios and hole size closely match the reference scan.
- GPT-5.6 Sol: pass: The block's length, width, height, and bore size appear visually consistent with the reference proportions.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 4.8: pass: The single through-hole, the only feature in the reference, is present in the clean part.
- GPT-5.6 Sol: pass: The single major feature in the reference, a round bore through the block, is present.
Pass:Those features sit where the reference has them
- Opus 4.8: pass: The hole sits off-center toward one side of the top face just as in the reference scan.
- GPT-5.6 Sol: pass: The bore is centered on the broad face in the same location shown by the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 4.8: pass: No extra geometry beyond the block and single hole appears in the renders.
- GPT-5.6 Sol: pass: The renders show no additional bosses, slots, chamfers, or decorative geometry.
Pass:A clean block with flat faces and one round hole — the scan's noise is gone
- Opus 4.8: pass: The rebuilt part has flat crisp faces and one round hole with the scan noise removed.
- GPT-5.6 Sol: pass: The produced part is a clean rectangular solid with flat faces, sharp edges, and one smooth round hole.
Pass:The hole is visible from both the top and bottom views
- Opus 4.8: pass: The hole appears as a dark opening in both the top and bottom orthographic views.
- GPT-5.6 Sol: pass: The circular opening is clearly visible in both the supplied top and bottom orthographic views.

Measured

✓ watertight: true == true
✓ one sub-part named block: ok
✓ bounding box within 0.5 mm of the mesh: ok
✓ volume within 5 % of the mesh: ok
✓ symmetric difference under the measured floor: ok
✓ the bore is 10 mm: ok
✓ the bore goes all the way through: ok
✓ the imported scan is still declared as an import: ok
✓ asked the oracle at most once: ok
✓ sweep length=30: length tracks the control: ok
✓ sweep length=50: length tracks the control: ok
✓ sweep boreDiameter=3: bore diameter tracks the control: ok
✓ sweep boreDiameter=12: bore diameter tracks the control: ok

Loading the transcript…

Run baseline-2026-092026-09-10commit 41aec7daspend $339.70 + $48.02 AI judging, 7 unpricedOther runs: 2026-09-04T20-02-10-stage2-hard-cases, 2026-09-04T19-48-31-screen-14-fixed
