Mesh add tabs

Kimi K3 Fast$2.214m 39s4m 38s waiting on the model3 builds, 1 failed

Reference
iso
front
back
top
bottom
left
right

96of 100

built: 85
geometry: 100
AI judge: 8 of 8

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The lid retains its recessed rectangular tray silhouette with two flat tabs added past the short ends, each carrying a hole.
- GPT-5.6 Sol: pass: The renders show the same rounded rectangular enclosure lid with its raised perimeter lip, plus one flat holed tab extending from each short end.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: Lid proportions match the reference and the tabs are modest extensions relative to the lid size.
- GPT-5.6 Sol: pass: The central lid retains the reference’s apparent length-to-width, corner-radius, rim, and plate-thickness proportions while the added tabs are symmetric.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The lid's recessed rim and lip are unchanged, plus the two requested tabs with through-holes are present.
- GPT-5.6 Sol: pass: The reference lid’s base plate, rounded outline, recessed central face, and raised perimeter lip are all visible in the result alongside the requested tabs and holes.
Pass:Those features sit where the reference has them, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: The tabs sit centered on each short end with holes in the middle, as requested.
- GPT-5.6 Sol: pass: The lid’s recessed face and perimeter lip remain in their reference positions, and the new tabs are centered on the two short ends.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry, allowing for the requested change: the lid itself unchanged, with two flat mounting tabs added past its short ends, each carrying one through-hole
- Opus 4.8: pass: Only the requested tabs and holes are added, no extra decorative geometry appears.
- GPT-5.6 Sol: pass: No decorative or unexplained raised geometry is visible beyond the requested pair of mounting tabs and their holes.
Pass:The tabs read as flat flanges continuing the lid's outer face, not posts, brackets or blocks bolted onto it
- Opus 4.8: pass: The side views show the tabs are thin flat flanges flush with the lid's lower outer face, not posts or blocks.
- GPT-5.6 Sol: pass: Side and perspective views show both tabs as thin, flat extensions coplanar with the lid’s base plate rather than posts or brackets.
Pass:Each tab carries exactly one round hole and no other openings
- Opus 4.8: pass: Each tab shows exactly one round hole and no other openings in the top and end views.
- GPT-5.6 Sol: pass: The top and underside views clearly show exactly one round opening in each tab and no additional tab openings.
Pass:Each tab is joined to the lid along its end rather than floating beside it or touching at a corner
- Opus 4.8: pass: The tabs join along the full short end of the lid, overlapping and continuous with it rather than floating.
- GPT-5.6 Sol: pass: Each tab visibly joins the lid along its corresponding short-end edge rather than floating or touching only at a corner.

Measured

✓ watertight: true == true
✓ one sub-part named lid: ok
✓ the imported lid is still declared as an import: ok
✓ the lid's own volume survives: ok
✓ nothing solid was added inside the lid's own footprint: ok
✓ the part spans 12 mm past the lid at both ends together: ok
✓ the tabs are on the short ends, not the long ones: ok
✓ the -X tab hole clears 3.4 mm at the 102 mm pitch: ok
✓ the +X tab hole clears 3.4 mm at the 102 mm pitch: ok
✓ the -X tab fills the lid's own thickness beyond its hole: ok
✓ the +X tab fills the lid's own thickness beyond its hole: ok
✓ asked the oracle at most once: ok
