Under-cabinet lid rack

S

by SouthernCalibama · published

clone this forge

git clone https://www.partforge.ai/git/p-3d47ebc26319.git

This clones the published version. Sign in as the owner to clone your latest work.

Under-cabinet lid rack — rendered image1 / 2

An under-cabinet holder for several large tumbler lids. Seen from above it is a smaller U inside a larger U. All the lids sit stacked in one level and slide in through the open end between the arms. It screws up into the cabinet underside through a flange. Adjust the number of lids, lid size and thickness, arm length, clearances and screw layout.

Designed by SouthernCalibama in PartForge, parametric CAD with an AI collaborator. Open it to view in 3D or export STL, 3MF or STEP.

License

Public domain dedication

You can build on this forge: its code may be copied into forges the assistant makes for you, always naming this license. No credit required.
