Photo lid then centred

Fable 5.1, effort high$1.382m 57s2m 56s waiting on the model3 builds, 1 failed

Reference
iso
front
back
top
bottom
left
right

93of 100

built: 85
geometry: 95
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 4.8: pass: Top-down render shows a rectangular tray with rounded corners, corner holes, and a grid of cells matching the reference silhouette.
- GPT-5.6 Sol: pass: The produced part is the same rectangular open tray/lid structure with a matching rounded outer silhouette.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 4.8: pass: The width-to-height ratio and 8-column grid layout closely match the reference proportions.
- GPT-5.6 Sol: pass: The top view shows a width-to-height ratio and border-to-interior proportions that closely match the reference.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 4.8: pass: Corner mounting holes, chamfered inner corners, and the rib grid are all present as in the reference.
- GPT-5.6 Sol: pass: The major perimeter walls, interior rib grid, diagonal corner regions, and four round corner pockets are all present.
Pass:Those features sit where the reference has them
- Opus 4.8: pass: Holes sit at the four corners and the grid fills the interior as in the reference.
- GPT-5.6 Sol: pass: The rib grid and round pockets occupy the same central and four-corner locations as in the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 4.8: pass: No extra decorative geometry appears beyond the tray, grid, and corner holes.
- GPT-5.6 Sol: pass: The renders show no clearly unexplained geometry beyond the tray walls, grid, corner cutoffs, and pockets seen in the reference.
Pass:Each inner corner is cut off diagonally and carries one small round pocket
- Opus 4.8: pass: Each inner corner is cut diagonally and carries a small round pocket, visible in the top view and isometric render.
- GPT-5.6 Sol: pass: All four inner corners are visibly cut diagonally and each contains one small round pocket.
Pass:An open tray whose walls stand well above the rib grid, with no lid, cover or ribs reaching the rim
- Opus 4.8: pass: The isometric render shows an open tray with walls standing above the rib grid and no lid or cover reaching the rim.
- GPT-5.6 Sol: pass: The perspective render clearly shows an uncovered tray with perimeter walls standing substantially above the low interior rib grid.

Measured

✓ watertight: ok
✓ one sub-part named lid: ok
✓ the apply was scored against the photo: ok
✓ silhouette matches the photo: ok
✓ length is 174.34 mm: ok
✓ width is 107 mm ± 10 %: ok
✓ height is 17.98 mm: ok
✓ the tray is hollow: ok
✓ the floor is solid: ok
✓ 7 ribs across the length on the 8-pocket pitch: ok
✓ 4 ribs across the width on the 5-pocket pitch: ok
✓ every pocket is open above its floor: ok
✓ the ribs stop below the rim: ok
✓ the straight-on photo joined scoring: ok
