Motor spoke

Gemini 3.8 Flash$0.545m 11s5m 1s waiting on the model9 builds, 2 failed

iso
front
back
top
bottom
left
right

84of 100

built: 70
geometry: 100
AI judge: 4 of 6

What the AI judge checked

Pass:A continuous outer ring around the edge of the face
- Opus 4.8: pass: A continuous outer ring is clearly visible around the edge of the face in the front views.
- GPT-5.6 Sol: pass: The renders clearly show an unbroken circular ring around the outer edge.
Pass:A distinct inner hub at the centre, separate from the outer ring
- Opus 4.8: pass: A distinct central hub with mounting holes is separate from the outer ring.
- GPT-5.6 Sol: pass: A distinct circular central hub with a center bore and four mounting holes is visible.
Pass:Spokes running radially from the hub out to the ring
- Opus 4.8: pass: Four spokes run radially from the hub out to the outer ring.
- GPT-5.6 Sol: pass: Four main spokes extend outward from the central hub toward the perimeter.
Fail:The spokes are curved, as in the reference photo, rather than straight bars
- Opus 4.8: fail: The main radial spokes are straight bars, with only decorative wavy arcs near the rim rather than curved spokes like the reference.
- GPT-5.6 Sol: fail: The hub-to-ring spokes are straight bars, while the curved elements are separate perimeter features rather than curved radial spokes.
Fail:Roughly the same number of spokes as the reference photo shows
- Opus 4.8: fail: The design shows only 4 spokes whereas the reference motor stator has many more segments.
- GPT-5.6 Sol: fail: The produced part has four main spokes, fewer than the roughly six-spoke pattern visible in the reference.
Pass:Each spoke meets both the hub and the outer ring cleanly, with no free-floating or stranded ends
- Opus 4.8: pass: Each spoke connects cleanly to both the hub and the outer ring with no free-floating ends.
- GPT-5.6 Sol: pass: All visible spokes join the hub and perimeter structure without free-floating or stranded ends.

Measured

✓ watertight: ok
✓ disc-like (flat, round): ok
✓ radially symmetric: ok
✓ has spoke openings: ok
