Mesh rebuild scan

DeepSeek V4.1 Flash, effort low$0.021m 36s1m 32s waiting on the model5 builds, 1 failed

Reference
iso
front
back
top
bottom
left
right

96of 100

built: 85
geometry: 100
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 4.8: pass: The rendered part is a rectangular block with a single round hole matching the scan's form and silhouette.
- GPT-5.6 Sol: pass: The result has the same rectangular block silhouette with a single circular opening as the reference.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 4.8: pass: The block's length-to-width-to-height proportions and hole size agree with the reference scan.
- GPT-5.6 Sol: pass: The rendered length, width, height, and bore size appear consistent with the reference proportions.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 4.8: pass: The single through-hole, the only major feature in the reference, is present.
- GPT-5.6 Sol: pass: The single major feature in the reference, a round bore through the block, is present.
Pass:Those features sit where the reference has them
- Opus 4.8: pass: The hole sits off-center toward the middle-front on the top face matching the reference location.
- GPT-5.6 Sol: pass: The bore is centered on the broad face in the same location shown by the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 4.8: pass: No extra geometry beyond the block and hole is visible.
- GPT-5.6 Sol: pass: No extra bosses, slots, fillets, or decorative geometry are visible in the result.
Pass:A clean block with flat faces and one round hole — the scan's noise is gone
- Opus 4.8: pass: The produced part has flat faces and one clean round hole with the scan noise removed.
- GPT-5.6 Sol: pass: The result shows planar faces, straight edges, and a clean round hole without the scan noise.
Pass:The hole is visible from both the top and bottom views
- Opus 4.8: pass: The hole appears dark/open in both top and bottom views indicating it passes fully through.
- GPT-5.6 Sol: pass: The circular opening is visible in both opposing broad-face views, clearly indicating a through-hole.

One reviewer

Verdict: acceptable (from the ranking's acceptable line, not typed on this attempt)

Measured

✓ watertight: true == true
✓ one sub-part named block: ok
✓ bounding box within 0.5 mm of the mesh: ok
✓ volume within 5 % of the mesh: ok
✓ symmetric difference under the measured floor: ok
✓ the bore is 10 mm: ok
✓ the bore goes all the way through: ok
✓ the imported scan is still declared as an import: ok
✓ asked the oracle at most once: ok
✓ sweep length=30: length tracks the control: ok
✓ sweep length=50: length tracks the control: ok
✓ sweep boreDiameter=3: bore diameter tracks the control: ok
✓ sweep boreDiameter=12: bore diameter tracks the control: ok
