Mesh rebuild scan

Opus 5, effort high$0.696m 2s5m 58s waiting on the model3 builds

Reference
iso
front
back
top
bottom
left
right

100of 100

built: 100
geometry: 100
AI judge: 7 of 7

What the AI judge checked

Pass:The overall form matches the reference: the same kind of object, the same silhouette from the matching angle
- Opus 4.8: pass: The clean rendered part is a rectangular block with a single round hole, matching the scanned block form and silhouette.
- GPT-5.6 Sol: pass: The produced part has the same rectangular block silhouette with a single top-facing circular bore as the reference.
Pass:Proportions match: the relative sizes of the major dimensions agree with the reference within what the eye can judge
- Opus 4.8: pass: The length, width, and height ratios of the clean block match the reference scan proportions.
- GPT-5.6 Sol: pass: The block’s length, width, height, and bore size appear visually consistent with the reference proportions.
Pass:Every major feature visible in the reference (holes, slots, bosses, tabs, lips) is present in the result
- Opus 4.8: pass: The single through-hole, the only feature in the reference, is present in the result.
- GPT-5.6 Sol: pass: The single major feature in the reference, a round bore through the block, is present.
Pass:Those features sit where the reference has them
- Opus 4.8: pass: The hole sits offset toward one end on the top face just as in the reference scan.
- GPT-5.6 Sol: pass: The bore is centered on the broad face in the same apparent location as in the reference.
Pass:Nothing is present that the reference does not show — no decorative or unexplained geometry
- Opus 4.8: pass: No extra geometry appears beyond the block and single hole.
- GPT-5.6 Sol: pass: The renders show no extra bosses, slots, chamfers, or decorative geometry.
Pass:A clean block with flat faces and one round hole — the scan's noise is gone
- Opus 4.8: pass: The rendered block has flat faces and one smooth round hole with the scan's surface noise removed.
- GPT-5.6 Sol: pass: The result is a clean rectangular block with planar faces, sharp edges, and one smooth round hole.
Pass:The hole is visible from both the top and bottom views
- Opus 4.8: pass: The hole appears dark and open in both the top and bottom orthographic views, indicating it passes through.
- GPT-5.6 Sol: pass: The circular opening is clearly visible in both opposing broad-face views, demonstrating a through-hole.

Measured

✓ watertight: true == true
✓ one sub-part named block: ok
✓ bounding box within 0.5 mm of the mesh: ok
✓ volume within 5 % of the mesh: ok
✓ symmetric difference under the measured floor: ok
✓ the bore is 10 mm: ok
✓ the bore goes all the way through: ok
✓ the imported scan is still declared as an import: ok
✓ asked the oracle at most once: ok
✓ sweep length=30: length tracks the control: ok
✓ sweep length=50: length tracks the control: ok
✓ sweep boreDiameter=3: bore diameter tracks the control: ok
✓ sweep boreDiameter=12: bore diameter tracks the control: ok
